Implementaiton Status

FedRAMP only accepts only one of five values for implementation-status: implemented, partial, planned, alternative, and not-applicable. A control may be marked "partial" and "planned" (using two separate implementation-status fields). All other choices are mutually exclusive.

If the implementation-status is partial, the gap must be explained in the remarks field.

If the implementation-status is planned, a brief description of the plan to address the gap, including major milestones must be explained in the remarks field. There must also be a prop (name="planned-completion-date" ns="http://fedramp.gov/ns/oscal") field containing the intended completion date. With XML, prop fields must appear before other sibling fields (such as set-parmeter, responsible-role, etc.), even though that sequence is counter-intuitive in this situation.

If the implementation-status is alternative, the alternative implementation must be summarized in the remarks field.

If the implementation-status is not-applicable, the N/A justification must be provided in the remarks field.

Representation

<!-- system-implementation -->
<control-implementation>
    <implemented-requirement uuid="uuid-value" control-id="ac-1">
        <prop name="planned-completion-date"
            ns="http://fedramp.gov/ns/oscal" value="2021-01-01Z"/>
        <prop name="implementation-status"
            ns="http://fedramp.gov/ns/oscal" value="implemented" />
        <prop name="implementation-status"
            ns="http://fedramp.gov/ns/oscal" value="partial" />
        <prop name="implementation-status"
            ns="http://fedramp.gov/ns/oscal" value="planned" />
        <prop name="implementation-status"
            ns="http://fedramp.gov/ns/oscal" value="not-applicable"/>
        <!-- responsible-role, statement, by-component -->
    </implemented-requirement>
</control-implementation>
<!-- back-matter -->

XPath Queries

Implementation Status (may return more than 1 result for a given control) :
    /*/control-implementation/implemented-requirement[@control-id="ac-1"] /prop[@name="implementation-status"]/@value
  Gap Description (If implementation-status="partial"):
    /*/control-implementation/implemented-requirement/prop[@name='implementation-status'][@value="partial"][@ns="http://fedramp.gov/ns/oscal"]/remarks/node()
  Planned Completion Date (If implementation-status="planned"):
    /*/control-implementation/implemented-requirement[@control-id="ac-1"]/prop[@name="planned-completion-date"][@ns="http://fedramp.gov/ns/oscal"]/@value
  Plan for Completion (If implementation-status="planned"):
    /*/control-implementation/implemented-requirement/prop[@name='implementation-status'][@value="planned"][@ns="http://fedramp.gov/ns/oscal"]/remarks/node()
  Not Applicable (N/A) Justification (If implementation-status="na"):
    /*/control-implementation/implemented-requirement/prop[@name='implementation-status'][@value="not-applicable"][@ns="http://fedramp.gov/ns/oscal"]/remarks/node()

The FedRAMP implementation-status property at the control's implemented-requirement level is a summary of all statement and/or component level core OSCAL implementation-status designations. It must be set appropriately based on the least value of child statement or component level implementation-status designations. When a statement and/or component level implementation-status designation is not specified, the FedRAMP implementation-status value is assumed. Individual statements and/or components may override implementation-status locally.
